Product description
Singlemode 9/125 um core, simplex, zipcord style, LC/UPC to FC/UPC fiber optic patch
cord. UPC stands for Ultra Physical Contact and represents one of the best ways of poli
shing for fiber ferrules, assuring a return attenuation greater than 50dB for singlemode
connections.
Technical specifications:
- typical insertion loss: 0.2 dB
- return loss > 53 dB
- fiber jacket 1.8mm, yellow color, zipcord style
- operating temperature: -40 to +75 Celsius degrees
- each cable assembly is manually tested and verified
- each cable assembly is individually sealed and labeled
- label mentions measured loss on patch cord
Product is guaranteed free of manufacturer defects. If any fault caused by manufacturing
process is found, product is replaced under warranty. Faults of manufacturing do not
include misuse or normal wear and tear of the product.
* 5m 10ft lc-lc sc singlemode simplex fiber optic optical patch cord cable 9/125 yellow
features applications: optical fiber communication systems; optical fiber access networks;
optical fiber data transmission; local area network (lan)
* Specification: indoor use only connector: sc to sccable type: simplexcore cladding
diameter single mode 9/125cable outer diameter (mm): 3mmnumber of plug: <1000
times working temperature: -40+80°c storage temperature range: -40+85°clength:
9. 8ft /3meterstandards: rohs compliant package includes1 x fiber optic patch cable.
* Can produce according to customer requirements
* Packaging : 1pcs with PE bag, many pcs in outer carton
